product type： jw-ds-01

application：(it’s suitable for powder raw materials weighing(particles, uneven, not afraid of crushed material）

            cement raw material and clinker batching,small granular materials of power,chemical,glass industry batching process;engineering plastics, modified plastics, chemical fiber pp, abs, pet in proportional ingredients mixing feeding;production batching process of small granules,such as food, medicine, grain, fodder, etc.batching process of daily chemical, fine chemical industry, fluorine chemical industry, washing powder,etc.

features :

1.special load cell with high precision and high standard;

2.loss-in-weight feeder can be applicable to automatic production of ingredients, reduces the labor

   cost, several  machines can also be used to weigh a variety of different materials at the same time,

   through adjusting the screw feeding flow to achieve continuous mixing weighing and packaging in

   proportion;

3.can choose batch weighing according to bag quantity, also can choose keep constant flow

    continuous weighing, use servo motor feeding control system, keep constant flow to feed material;

4.according to the production situation can be directly modify the parameters in operation, the

   operation is simple and convenient.user can operate the weigher by hmi,rs-485a online or data

   online;

5.double screw feeder is mainly for powder, powder mixture, glass fiber, and thin sheet,etc, which the

    material is in bad flowability and sticky(material being crushed is acceptable).single screw feeder is

    mainly for most of uniform and easy flow granules, especially for new material, can make high repeat

    accuracy and linear precision.

mechanical character :

1.contact material parts are made of stainless steel 304, safety and hygiene;

2.machine structure is simple, easy to install and clean;storage hopper and screw discharging part can

   be quickly disassembled;

3.reasonable structural design to reduce the running vibration to the minimum;the sealed structure to

   avoid the bad environment effect of weighing accuracy.

technical specification ：
